There should be no other Salad Fork like YOUR Salad Fork. Stop buying standard kits just to build someone else's miniature trident. Welcome to West3D's signature Configurator for the Salad Fork v1.1 (180mm).
PRE-SALE & BETA NOTICE: This initial release is offered as a pre-sale and should be considered a beta version. Please expect a pre-shipment notification approximately 2-4 weeks following your order. If you encounter any issues during your build, reach out to us directly so we can make it right! Pre-sales are fully refundable up until the date of shipment, minus a 3.5% transaction processing fee. Note: Configurator orders are not eligible for additional promotional offers.
EXCLUSIVE WEST3D BONUS: We are including a custom name plate completely free with every kit you get serial'd!
What is a Configurator Kit?
When building a custom 3D printer, you are usually left with two choices:
- Buy a standard kit: You end up replacing a bunch of parts you don't like (swapping out for better quality, alternative hotends, or better performance). This is costly, wasteful, and leaves you with spare parts you don't need.
- Self-source everything: While tried and true, self-sourcing is a logistical headache, adds massive shipping costs from multiple vendors, and takes forever.
West3D’s signature configurator gives you the ultimate "easy button." We have compiled the highest-quality and most complete base kit on the market while keeping the freedom of self-sourcing intact. You get the benefit of bundled pricing discounts and zero sourcing screen-time, backed by prompt, US-based customer support.
What makes our kit different? Unlike bare-bones kits, this package includes a premium custom-designed wiring harness (engineered and tested in-house), a Raspberry Pi, a high-performance Hotend, and core electronics. It includes virtually everything you need to get up and running except for your own 3D-printed structural parts and tools.
Prerequisites: To successfully complete the Salad Fork v1.1 build, you should possess a working knowledge of 3D printer mechanics, electronics, custom wiring/crimping, basic coding, and a healthy dose of patience. Due to the modular nature of configurators, deviating heavily from standard build paths may require extra fasteners or wire extensions.
📋 Base Bill of Materials (BOM)
Below is the complete list of high-grade components included in the base kit. Items marked as Configurable can be customized in the dropdown menus to fit your exact specifications.
| Section | Component Description | Qty | Customizable? |
|---|---|---|---|
| Frame (1515 Extrusions) | HFS3-1515-290 | 3 | Standard (Fixed) |
| HFS3-1515-320 | 6 | Standard (Fixed) | |
| HFS3-1515-400 | 4 | Standard (Fixed) | |
| HFS3-1515 Misc Lengths (190mm, 195mm, 229mm, 260mm) | 1 ea. | Standard (Fixed) | |
| Linear Rails | BERSERKER MGN7H (200mm / 250mm) | 3 / 2 | Standard (Fixed) |
| BERSERKER MGN9H (230mm) | 1 | Standard (Fixed) | |
| Motion & Motors | F623 Bearings / GE5C Bearings | 24 / 3 | Yes (Upgrade Options available) |
| Genuine Gates GT2 RF Belt (6 meters) & Pulleys | 1 | Yes (EPDM options available) | |
| LDO 35STH52-1504 Stepper Motors | 2 | Standard (Fixed) | |
| LDO 36STH20-1004AHG Extruder Motor (9T) | 1 | Yes (G2E / Orbiter variants) | |
| LDO 42STH25-1004CL200ET Z-Motors | 3 | Standard (Fixed) | |
| Print Bed | West3D Mic6 Precision Aluminum Bed | 1 | Yes (Standard or Magbed setup) |
| West3D 320W High-Output Silicone Heater & 150C Thermal Fuse | 1 | Standard (Fixed) | |
| West3D Double-Sided Smooth/Textured PEI Sheet (185x185mm) | 1 | Standard (Fixed) | |
| Toolhead & Extruder | Phaetus Rapido 2 HF High-Flow Hotend | 1 | Yes (Multiple configurations) |
| Dual-Drive BMG Internal Gear Set & Premium Fans | 1 set | Yes (Adapts to toolhead selection) | |
| Electronics & Control | Pancake Toolhead Breakout Board | 1 | Yes (Nitehawk, EBB, etc.) |
| BigTreeTech Octopus Mainboard | 1 | Yes (Leviathan, M8P, Kraken, etc.) | |
| Genuine Raspberry Pi 4 Controller & PiTFT43 Touchscreen Display | 1 ea. | Standard (Fixed) | 1 | Standard (Fixed) |
| Panasonic AQA211VL 15A Solid State Relay (SSR) & DIN Rail Mounts | 1 set | Standard (Fixed) | |
| Fasteners & Hardware | Complete SS304 Stainless Steel Screw, Nut, Heatset & Magnet Kit | 1 kit | Includes all core assembly hardware |
Have a unique hardware configuration or want to see a specific component option added to our menus? Drop us a line at info@west3d.com and let us know!
