FireX Sintering Kiln – Compact Metal & Ceramic 3D Printing Kiln

FireX Sintering Kiln

The FireX Sintering Kiln is a compact, high-temperature kiln designed for sintering metal, ceramic, and glass 3D printed parts with ease.

Engineered for reliable desktop-scale metal sintering, this kiln reaches temperatures up to 1260°C / 2300°F and features a user-friendly touchscreen controller for simplified operation.

Estimated Lead Time: Up to 17 weeks

How It Works

The sintering process is straightforward:

1. 3D print your part
2. Pack the part in refractory ballast
3. Cover with sintering carbon
4. Load into the kiln
5. Select your sintering settings and begin the cycle

Once complete, your printed parts are transformed into durable, functional metal components.

Compatible Materials

• Bronze
• Copper
• H13 Tool Steel
• Inconel 718
• M300 Tool Steel
• Stainless Steel 17-4
• Stainless Steel 316L
• Pyrex® (Borosilicate)
• Amaco 46-D

Electrical Specifications

Specification	Details
Power Input	115V, 15A, 1800W, 50/60Hz, Single Phase
Maximum Temperature	1260°C / 2300°F
Controller	Mini Touchscreen Controller
Plug Type	5-15P
Certification	UL Listed

Dimensions

Measurement	Dimensions
Sintering Chamber	8" W × 8" D × 6" H (203mm × 203mm × 152mm)
Outer Dimensions	15" W × 20.5" D × 14.5" H (381mm × 521mm × 368mm)
Shipping Weight	Approximately 58lbs

Shipping & Availability

• Ships via UPS
• Available only within the USA
• Estimated Lead Time: Up to 17 weeks

Important Safety Information

Proper ventilation is required during operation. This kiln reaches extremely high temperatures and should only be operated with appropriate safety precautions.
