Upgrade your industrial 3D printing capabilities with FibreX™ ABS+GF, a high-performance glass-fiber reinforced ABS filament engineered in the USA. Formulated specifically for demanding applications, this engineering composite combines high-grade ABS with strategically aligned glass fibers to deliver exceptional mechanical stiffness, high heat resistance, and superior dimensional stability.
FibreX™ ABS+GF effectively addresses the traditional challenges of printing standard ABS by drastically reducing thermal shrinkage and warping. It is the ideal choice for load-bearing structural parts, functional prototypes, manufacturing jigs, and custom fixtures requiring rigid performance and tight tolerances.
Key Features
High Mechanical Rigidity: Glass fiber reinforcement provides outstanding tensile strength and stiffness for heavy-duty structural parts.
Superior Dimensional Stability: Significantly reduces warping, lifting, and thermal shrinkage compared to unreinforced ABS.
Elevated Thermal Resistance: Maintains structural integrity under load up to 98°C.
Consistent Industrial Extrusion: Formulated for clean, reliable layer adhesion and high dimensional tolerance (1.75mm ± 0.05mm).
Recommended Print Settings
Parameter
Recommended Value
Extruder Temperature
230°C – 245°C
Bed Temperature
95°C – 110°C
Chamber Temperature
30°C – 80°C (Heated enclosure recommended)
Nozzle Type
0.4mm or larger (Hardened Steel Required)
Layer Height
0.25mm or higher
Drying Parameters
80°C for 4 hours
Specifications & Hardware Requirements
Brand: FibreX™
Base Polymer: ABS + Glass Fiber Reinforcement
Diameter: 1.75mm (± 0.05mm)
Available Sizes: 750g, 2kg, and 4kg spools
Origin: Made in the USA
Abrasion Notice: Glass fibers are highly abrasive. A hardened steel nozzle is strictly required to prevent rapid nozzle wear and extrusion degradation.
